Load Balancing

UniversityLite Load Balancing

UniversityLite, an e-commerce rapid deployment tool I developed in 2016, is load balanced across three Ubuntu 14.04 LTS virtual servers located in New York, NY with one backup server in Webster, NY. The three primary servers are balanced alphabetically by university name. There are 7,000 websites available as subdomains off of the universitylite.com domain (such as rit.universitylite.com). Each subdomain is given resources by the server only if actively being viewed. As seen in the image below, an arbitrary university named ‘David’s University College’ would be hosted on Server1. Because the functions and algorithms to create any of the A-Z universities resides on each ot the servers, the balancing is done for resource balancing, not necessarily content balancing.

UniversityLite Server Balance
UniversityLite Server Balance

Because of the large set of active subdomains, load balancing through DNS would be cumbersome and time consuming as partial wildcards (such as a*.universitylite.com) in a DNS zone are not defined behavior within the RFC. Manually adding a record for rit.universitylite.com, for example, would also require us to add a manual record for the 6,999 other subdomains. Therefor a DNS zone can only practicaly be used with full wildcards such as *.universitylite.com to to one of the universitylite.com servers. As a result, load balancing is handled first by the Apache virtualhost file, and then subsequently by PHP logic once the subdomain is called.

As seen in the function below, we can query the SQL table once a subdomain passed to the UniversityLite webserver. If the subdomain is found as a SQL entry, we can go ahead and assume the server referenced is the correct load balanced server. However, if it isn’t, we a) either can assume it’s load balanced on one of the other servers or b) it is simply not a valid subdomain anywhere on the site. For example, trying to go to gaboldygooky.universitylite.com will fail all load balancing checks and return an error to the browser.

UniversityLite PHP Load Balance Example
UniversityLite PHP Load Balance Example

In this way, I have created a dynamic load balancing system that allows sites to be added and removed ad-hoc without having to alter DNS. Of course, this is just general domain load balancing, and we must further balance the content itself. There are, afterall, 7,000 different subdomains with uniquely generated HTML, photos, graphs, etc. The easiest way I found to handle this is by having UniversityLite just be one central source of programming code, and to allow other content to be displayed dynamically when required. That is not to say, however, that each site can be dynamically created each time it is viewed, but we can remove some redundancy from the equation.

Below are areas of dialy generated content that CAN be shared between them, assuming the same calculator with description, etc. might be viewed by more than one subdomain. This data alone amounts to about 10GB of freshly generated content for a 24 hour period for the sites on server1. If we did not consolidate this data, this could easily have grown to 23TB of data in just 24 hours on one server.

Directory List of ~/www/universitylite.com/public_html/sites/shared$:

drwxr-xr-x 2 maiolo99 maiolo99 4096 Oct 20 16:49 adpics
drwxr-xr-x 7 maiolo99 maiolo99 4096 Oct 20 21:29 amazon_xml
drwxr-xr-x 2 maiolo99 maiolo99 4096 Sep 23 18:07 apparel_images
drwxrwx--- 2 maiolo99 maiolo99 4096 Sep 18 16:54 avatars
drwxrwx--- 2 maiolo99 maiolo99 4096 Jul 26 23:29 holidays
drwxr-xr-x 356 maiolo99 maiolo99 20480 Oct 8 00:30 ms_images
drwxr-xr-x 2 maiolo99 maiolo99 7966720 Oct 21 16:51 product_images

However, sometimes there is only so much we can do. As seen in the directory listing below, these files are created uniquely for one of the subdomains (mcc.universitylite.com) below. This information is perfectly unique to Monroe Community College, and there is nothing we can really do about it.

Directory Listing of ~/www/universitylite.com/public_html/sites/MCCTextbooks:

./daily_message:
MonroeCommunityCollege_20161019_daily.txt

./graphs-2016-09-19:
graph_MCC_All Instructional Staff Total_1473662381.jpg
graph_MCC_All Instructional Staff Total_1473662723.jpg
graph_MCC_All Instructional Staff Total_1473722731.jpg
graph_MCC_All Instructional Staff Total_1473773589.jpg
graph_MCC_All Instructional Staff Total_1473791287.jpg
graph_MCC_All Instructional Staff Total_1473813691.jpg
graph_MCC_All Instructional Staff Total_1474227934.jpg
graph_MCC_All Instructional Staff Total_1474457249.jpg
graph_MCC_All Instructional Staff Total.jpg
graph_MCC_Assistant Professor_1473662380.jpg
graph_MCC_Assistant Professor_1473662722.jpg
graph_MCC_Assistant Professor_1473722730.jpg
graph_MCC_Assistant Professor_1473773588.jpg
graph_MCC_Assistant Professor_1473791286.jpg
graph_MCC_Assistant Professor_1473813690.jpg
graph_MCC_Assistant Professor_1474227933.jpg
graph_MCC_Assistant Professor_1474457248.jpg
graph_MCC_Assistant Professor.jpg
graph_MCC_Associate Professor_1473662379.jpg
graph_MCC_Associate Professor_1473662722.jpg
graph_MCC_Associate Professor_1473722730.jpg
graph_MCC_Associate Professor_1473773588.jpg
graph_MCC_Associate Professor_1473791286.jpg
graph_MCC_Associate Professor_1473813690.jpg
graph_MCC_Associate Professor_1474227932.jpg
graph_MCC_Associate Professor_1474457248.jpg
graph_MCC_Associate Professor.jpg

./weather:
Rochester_NY_Weather_2016-09-19.txt

./wiki_infobox-2016-10-19:
Bevier20Memorial20Building(BevierMemorialBuilding)_intro_request_phase2.xml
Bevier20Memorial20Building_intro_request_phase1.xml
Bridge20Square20Historic20District(BridgeSquareHistoricDistrict)_intro_request_phase2.xml
Bridge20Square20Historic20District_intro_request_phase1.xml
Campbell-Whittlesey20House(Campbell-WhittleseyHouse)_intro_request_phase2.xml
Campbell-Whittlesey20House_intro_request_phase1.xml
First20Presbyterian20Church20(Rochester20New20York)(FirstPresbyterianChurch(RochesterNewYork))_intro_request_phase2.xml
First20Presbyterian20Church20Rochester20New20York_intro_request_phase1.xml
Hervey20Ely20House(HerveyElyHouse)_intro_request_phase2.xml
Hervey20Ely20House_intro_request_phase1.xml
Immaculate20Conception20Church20(Rochester20New20York)(ImmaculateConceptionChurch(RochesterNewYork))_intro_request_phase2.xml
Immaculate20Conception20Church20Rochester20New20York_intro_request_phase1.xml
Jonathan20Child20House2020BrewsterBurke20House20Historic20District_intro_request_phase1.xml
Jonathan20Child20House2020BrewsterBurke20House20Historic20District(JonathanChildHouseampBrewsterBurkeHouseHistoricDistrict)_intro_request_phase2.xml
Main2020Oak20RIRTR20station_intro_request_phase1.xml
Main2020Oak20(RIRTR20station)(Main)_intro_request_phase2.xml
Monroe20Community20College20_intro_request_phase1.xml
Monroe20Community20College20(MonroeCommunityCollege)_intro_request_phase2.xml
Monroe20Community20College20Sports_intro_request_phase1.xml
Monroe20Community20College20Sports(UniversityofLouisianaatMonroe)_intro_request_phase2.xml
Monroe20Community20College20Team_intro_request_phase1.xml
Monroe20Community20College20Team(UniversityofLouisianaatMonroe)_intro_request_phase2.xml
Monroe20Community20College20Tribunes20_intro_request_phase1.xml
Monroe20Community20College20Tribunes20(ListofcollegeathleticprogramsinNewYork)_intro_request_phase2.xml
Monroe20Community20College20Tribunes_intro_request_phase1.xml
Monroe20Community20College20Tribunes(ListofcollegeathleticprogramsinNewYork)_intro_request_phase2.xml
Monroe20Community20College_intro_request_phase1.xml
Monroe20Community20College(MonroeCommunityCollege)_intro_request_phase2.xml
MonroeCommunityCollege_infobox.xml
Nick20Tahou20Hots_intro_request_phase1.xml
Nick20Tahou20Hots(NickTahouHots)_intro_request_phase2.xml
RochesterNewYork_infobox.xml
RochesterNY_geosearch.json
Third20Ward20Historic20District20Rochester20New20York_intro_request_phase1.xml
Third20Ward20Historic20District20(Rochester20New20York)(ThirdWardHistoricDistrict(RochesterNewYork))_intro_request_phase2.xml

./youtube-2016-10-19:
BevierMemorialBuildingRochesterNY_youtube_2016-10-19.txt
BridgeSquareHistoricDistrictRochesterNY_youtube_2016-10-19.txt
Campbell-WhittleseyHouseRochesterNY_youtube_2016-10-19.txt
FirstPresbyterianChurchRochesterNewYork_youtube_2016-10-19.txt
geosearch-431012652C-77608488--searchquery-_youtube.txt
geosearch-Rochester-NY--searchquery-RochesterNYMusic_youtube.txt
HerveyElyHouseRochesterNY_youtube_2016-10-19.txt
ImmaculateConceptionChurchRochesterNewYork_youtube_2016-10-19.txt
JonathanChildHouseBrewsterBurkeHouseHistoricDistrictRochesterNY_youtube_2016-10-19.txt
MainOakRIRTRstationRochesterNY_youtube_2016-10-19.txt
MonroeCommunityCollegeSports_youtube_2016-10-19.txt
MonroeCommunityCollege_youtube_2016-10-19.txt
NickTahouHotsRochesterNY_youtube_2016-10-19.txt
ThirdWardHistoricDistrictRochesterNewYork_youtube_2016-10-19.txt

The best we can do with this data is purge it (beyond what we might want to keep for historical purposes). We do this by adding historically usable data into a SQL table for that university, and simply deleting the rest.

SUMMARY

The load balancing techniques used on UniversityLite have allowed us to maintain 7,000 unique websites, on only three servers.
